Description

• CSV series double-suction vertical in-line centrifugal pumps are equipped with standart motors and mechanical seals.
• The impellers of CSV type pumps are (full) radial, double- sloped (Francis type) or mixed flow types.
• Bearing isprovided with two grease lubricated, 6300 C3-type deep groove ball bearings according to DIN 625.
• TEFC (Totally Enclosed Fan Cooled) 3 phase, squirrel caged, in accorrdance to DIN 42673, IM 2001B35 type (with flange) electrical motor which complies with DIN IEC and VDE is used to drşve the pump in proper speed and power.
• CSV series are used successfully in large-capacity water transfer in tight spaces thanks to their compact structurew, highly efficient construction and the impeller geometry.
